EAVISION J150
Engineered for precision, safety, and efficiency, the J150 delivers powerful performance in even the toughest field conditions.
- 85kg payload capacity for high‑volume spraying,spreading and lifting
- 360 degree Obstacle Avoidance - LIDAR + Radar
- 4-10 M swath, 40 L/min Flow Rate for maximum output
- Built for large blocks, steep terrain & high‑volume programs
- High‑efficiency spray system with uniform droplet distribution and reduced drift
- Low operating cost compared to traditional ground rigs or manual labor
Ready-to-Spray Package
$44,850
With 360 LiDAR + Radar Obstacle Avoidance
RC + ag software, 3x Batteries, Fast Charger, 73L spray tank
Add-on Options
Broadcast Spreader
85 kg Rated Load
$2400
RTK/Relay
cm-Level Accuracy
$3400
Lift Kit
55 kg Max Lift Capacity
$850
EAVISION Drones
for Safety & Efficiency
Precision Spray Performance
Advanced Liquid Application
Ensures uniform droplet coverage across crops. Optimized for large-scale spraying tasks.
High-Capacity Granular Distribution
Efficient Spreading Operations
Designed for fast and even material distribution.
Ideal for fertilizer and seed applications.
Advanced Obstacle Detection
360t Avoidance System
Detects and avoids obstacles in complex terrain. Enhances safety during low-altitude operations.
Heavy Payload Handling
Built for Demanding Loads
Supports high-capacity lifting with stable flight. Designed for intensive agricultural missions.
Low-Light Operation Capability
Reliable Night-Time Flights
Maintains stable and accurate performance after dark. Extends operational hours during peak seasons.
Topographic Mapping
HD Camera on Board
Monitor application flight in real-time, fly visually to set boundary points, create an orthomosaic map for accurate crop field assessment.
| Feature | EA-J150 | EA-J70 |
|---|---|---|
| Liquid Tank Capacity | 73 L | 45 L |
| Spray Flow Rate (Max) | 40 L / Min | 24 L / Min |
| Spreading Rate (Max) | 280 L / Min | — |
| Number of Nozzles | 2 or 4 | 2 |
| Granular Tank Capacity | 85 Kg | 55 Kg |
| Spreading Flow Rate (Max) | 280 Kg / Min | 240 Kg / Min |
| Max Spray Width | 4 – 15 m | 3 – 8 m |
| Coverage (Max) | Up to 60+ Acres / Hour | Up to 50 Acres / Hour |
| Speed (Max) | 13.8 m / sec | 13.8 m / sec |
| Adjustable Droplet Sizes | 10 – 500 μm | 10 – 500 μm |
| 360° Obstacle Avoidance | Yes | Yes |
| Lifting Capacity (Max) | 75 Kg | 60 Kg |
| Vertical Transport Height | 100 m | — |
| Battery | Intelligent Battery System | Intelligent Battery System |
| Terrain Following Radar | Yes | Yes |
| Remote Controller | EAVISION | EAVISION |
| Recommended Farm Size | Large Farm / Custom Operators | Small to Medium Sized Farms |
| Dimensions (Fully Unfolded) | 132.9" × 138.2" × 37.4" | 113.4" × 126" × 35.4" |
| Dimensions (Arms Folded) | 52.2" × 31.3" × 37.4" | 47.2" × 26.4" × 35.4" |
| Dimensions (Propellers Folded) | 77.4" × 82.1" × 37.4" | 67.7" × 73.2" × 35.4" |
